Color: 0.002lux@ (F1.5, ACG ON), BW: 0lux with IR |
Shutter Time |
1s to 1/100,000s |
Day & Night |
Dual IR Cut Filter |
Wide Dynamic Range |
140dB |
Optical Zoom |
30× |
Digital Zoom |
16× |
Focal Length |
4.7mm~141mm |
Zoom Speed |
<5s |
Angle of View |
Horizontal filed of view: 69.5° (w)~ 2.7° (t) |
Aperture Range |
F1.5~F4.0 |
Pan Range |
360° |
Pan Speed |
Pan Manual Speed: 0.1°~180°/s, Pan Preset Speed: 240°/s |
Tilt Range |
-16°~90° (Auto flip) |
Tilt Speed |
Tilt Manual Speed: 0.1°~120°/s, Tilt Preset Speed: 180°/s |
3D Position |
Yes |
Presets |
500 |
Preset Accuracy |
±0.4° |
Scan |
8 |
Cruise |
16, up to 32 presets per cruise |
Pattern |
8, each with 600s memory or 1000 orders |
Power-off Memory |
Yes |
RS-485 Protocols |
DOME_PELCO_D, DOME_PELCO_P, DOME_PLUS |
IR LEDs |
8 |
IR Range |
Up to 150m |
IR Irradiation Angle |
Adjustable by Zoom |
White LEDs |
2 |
Video Compression |
S+265/H.265/H.264/M-JPEG |
Video Bit Rate |
32 Kbps to 16 Mbps |
Audio Compression |
G.711A/G.711U/ADPCM/AAC |
Audio Bit Rate |
8K~48Kbps |
Max. Resolution |
2592×1944 |
PAL: 25fps (2592×1944, 2560×1920, 2592×1520, 2560×1440, 2048×1536, 1920×1080, 1280×960,
1280×720) |
Main Stream |
NTSC: 30fps (2592×1944, 2560×1920, 2592×1520, 2560×1440, 2048×1536, 1920×1080, 1280×960,
1280×720) |
PAL: 25fps (704×576, 704×288, 640×360, 352×288) |
Sub Stream |
NTSC: 30fps (704×480, 704×240, 640×360, 352×240) |
PAL: 25fps (1920×1080, 1280×960, 1280×720, 640×480, 704×576, 352×288) |
Third Stream |
NTSC: 30fps (1920×1080, 1280×960, 1280×720, 640×480, 704×480, 352×240) |
Image Setting |
Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
Image Enhancement |
BLC/3D DNR/HLC |
ROI |
7 Dynamic Areas for Both Main and Sub Stream, support auto-tracking ROI |
OSD |
16×16, 24×24,32×32, 48×48, 64×64, 96×96, adaptable size, Letters Such as Week, Date, Time, Total
5 Regions |
Camera |
Lens |
Pan&Tilt |
Illuminator |
Compression Standard |
Image |
