30°C (86°F) to 45°C (113°F) |
FOV |
Horizontal field of view: 51° |
Measurement Accuracy |
±0.5 |
Measurement Distance |
0.5m~3m |
Optical Module |
Image Sensor |
1/1.8″ CMOS |
Signal System |
PAL/NTSC |
Min. Illumination |
Color: 0.0002Lux@ (F1.0, AGC ON), B/W: 0Lux with IR |
Shutter Time |
1s to 1/100,000s |
Day & Night |
Dual IR Cut Filter with Auto Switch |
Wide Dynamic Range |
120dB |
Lens |
Lens Type |
Fixed |
Focus |
4mm |
Lens Mount |
M12 |
Aperture |
F1.0 |
FOV |
Horizontal field of view: 90° |
Illuminator |
IR LEDs |
N/A |
IR Range |
N/A |
Wavelength |
N/A |
White LEDs |
1 |
Compression Standard |
Video Compression |
S+265/H.265/H.264/M-JPEG |
Video Bit Rate |
32 Kbps to 16 Mbps |
Audio Compression |
G.711A/G.711U/ADPCM/AAC |
Audio Bit Rate |
8K~48Kbps |
Image |
Max. Resolution |
2560×1440 |
Main Stream |
PAL: 25fps (2560×1440, 1920×1080, 1280×720, 704×576), Thermal: 25fps (1280×960, 1024×768, 640×480,
256×192) |
Sub Stream |
PAL: 25fps (704 576, 640 360, 352 288) |
NTSC: 25fps (704 576, 640 360, 352 288) |
Third Stream |
1920 1080, 1280 720, 704 576, 640 480, 352 288 |
Image Setting |
Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
Image Enhancement |
BLC/3D DNR/HLC |
ROI |
Support 7 fixed region of coding |
OSD |
16 16, 24 24,32 32, 48 48, 64×64, 96×96, adaptable size, Letters Such as Week, Date, Time, Total 5 Regions |
Picture Overlay |
Yes |
Privacy Mask |
Yes |
Smart Defog |
Yes |
NTSC: 25fps (2560×1440, 1920×1080, 1280×720, 704×576), Thermal: 25fps (1280×960, 1024×768, 640×480,
256×192) |
