Image Sensor |
1/2.8″ CMOS |
Signal System |
PAL/NTSC |
Min. Illumination |
Color:0.002Lux@(F1.6,AGC ON),B/W:0Lux with IR |
Shutter Time |
1s to 1/100,000s |
Day & Night |
Dual IR Cut Filter with Auto Switch |
WDR |
120dB |
Angle Adjustment |
pan 0~340°,tilt 0~75°,roate 0~360° |
Lens |
Lens Type |
Fixed |
Focus |
2.8mm |
Lens Mount |
M12 |
Aperture |
F1.6 |
FOV |
Horizontal field of view:94.7°; Vertical field of view:71.2° |
Illuminator |
IR LEDs |
2 |
IR Range |
Up to 30m |
Wavelength |
850nm |
White LEDs/Warmlights |
N/A |
Compression Standard |
Video Compression |
S+265/H.265/H.264 |
Video Bit Rate |
32Kbps~6Mbps |
Audio Compression |
G.711A/G.711U/ADPCM_D_D |
Audio Bit Rate |
8K,32K,48Kbps |
Image |
Max. Resolution 2592×1944 |
Main Stream PAL:20fps(2592×1944),25fps(2592×1520,2560×1440,2304×1296,1920×1080,1280×720)
NTSC:20fps(2592×1944),24fps(2592×1520,2560×1440),30fps(2304×1296,1920×1080,1280×720) |
Sub Stream PAL:25fps(704×576,704×288,640×360,352×288)
NTSC:30fps(704×480,704×240,640×360,352×240) |
Third Stream N/A |
Image Setting Saturation,brightness,contrast,sharpness,adjustable by client software or web browser |
Image Enhancement BLC/3D DNR/HLC |
ROI Support 8 fixed regions of coding |
OSD |
16×16,32×32,48×48,64×64,adaptable size,Letters Such as Week,Date,Time,Total 1 Regions |
Picture Overlay N/A |
Privacy Mask Yes,4 regions |
Smart Defog Yes |
Feature |
Alarm Trigger |
Motion Detection,Mask Alarm,IP Address Conflict |
Video Analytics |
Tripwire,Perimeter |
Early Warning(EW) |
N/A |
