ination |
Color: 0.0004Lux@ (F1.2, ACG ON), B/W: 0Lux with IR |
Shutter Time |
1s to 1/100,000s |
Day & Night |
Dual IR Cut Filter with Auto Switch |
Wide Dynamic Range |
120dB |
Angle Adjustment |
Bracket, pan 0~360°, tilt 0~75°, roate 0~360° |
Lens |
Lens Type |
Motorized |
Focus |
2.7-13.5mm |
Lens Mount |
14 |
Aperture |
F1.2~F2.2, DC |
FOV |
Horizontal field of view: 103.9° ~ 35.3° |
Illuminator |
IR LEDs |
4 |
IR Range |
Up to 80m |
Wavelength |
850nm |
White/Warmlight LEDs |
N/A |
Compression Standard |
Video Compression |
S+265/H.265/H.264/M-JPEG |
Video Bit Rate |
32Kbps~8Mbps |
Audio Compression |
G.711A/G.711U/ADPCM_D/AAC_LC |
Audio Bit Rate |
8K~48Kbps |
Image |
Max. Resolution |
1920×1080 |
Main Stream |
PAL: 25fps (1920×1080, 1280×720, 704×576, 640×480) |
Sub Stream |
PAL: 25fps (704×576, 704×288, 640×360, 352×288) |
Third Stream |
PAL: 25fps(704×576, 704×288, 352×288) NTSC: 30fps(704×480, 704×240, 352×240) |
Image Setting |
Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
Image Enhancement |
BLC/3D DNR/HLC/Corridor Format |
ROI |
Support 8 fixed regions of coding |
OSD |
16×16, 32×32, 48×48, 64×64, adaptable size, Letters Such as Week, Date, Time, Total 8 Regions |
Picture Overlay |
Yes |
Privacy Mask |
Yes, 4 regions |
Smart Defog |
Yes |
Feature |
Alarm Trigger |
Event Input, Event Output, Motion Detection, Mask Alarm, Disk Full, Disk R/W Error, IP Address
Conflict, MAC Address Conflict, FTP Server Exception, Voltage Abnormal |
Video Analytics |
Tripwire, Double Tripwire, Perimeter, Object Abandon, Object Lost, Loitering, Running, Parking,
Crowed, People Counting, Crowed, On Duty Detection, Video Abnormal, Audio Abnormal, Heatmap,
Face Capture(Face Detection), Human/Vehicle Classification |
Early Warning(EW) |
N/A |
NTSC: 30fps (704×480, 704×240, 640×360, 352×240) |
NTSC: 30fps (1920×1080,1280×720, 704×480, 640×480) |
