PAL/NTSC |
Min. Illumination |
Color: 0.002Lux@ (F1.8, ACG ON), B/W: 0Lux with IR |
Shutter Time |
1s to 1/100,000s |
Day & Night |
Dual IR Cut Filter with Auto Switch |
Wide Dynamic Range |
120dB |
Angle Adjustment |
Bracket, pan 0~360°, tilt 0~75°, roate 0~360° |
Lens Type |
Motorized |
Focus |
2.8-12mm |
Lens Mount |
Φ14 |
Aperture |
F1.8~F3.3, Fixed |
FOV |
Horizontal field of view: 101.7°~32.3° |
IR LEDs |
4 |
IR Range |
Up to 80m |
Wavelength |
850nm |
White LEDs |
N/A |
Video Compression |
S+265/H.265/H.264/M-JPEG |
Video Bit Rate |
32Kbps~16Mbps |
Audio Compression |
G.711A/G.711U/ADPCM_D/AAC_LC |
Audio Bit Rate |
8K~48Kbps |
Max. Resolution |
3840×2160 |
PAL: 20fps (3840×2160), 25fps (3072×1728, 2560×1440, 1920×1080, 1280×960, 1280×720) |
Main Stream |
NTSC: 20fps (3840×2160), 30fps (3072×1728, 2560×1440, 1920×1080, 1280×960, 1280×720) |
PAL: 25fps (704×576, 704×288, 640×360, 352×288) |
Sub Stream |
NTSC: 30fps (704×480, 704×240, 640×360, 352×240) |
Third Stream |
720P |
Image Setting |
Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
Image Enhancement |
BLC/3D DNR/HLC/Corridor Format |
ROI |
Support 7 fixed region of coding |
OSD |
16×16, 24×24,32×32, 48×48, 64×64, 96×96, adaptable size, Letters Such as Week, Date, Time, Total
5 Regions |
Picture Overlay |
Yes |
Privace Mask |
Yes |
Smart Defog |
Yes |
Alarm Trigger |
Event Input, Event Output, Motion Detection, Mask Alarm, Disk Full, Disk R/W Error, IP Address
Conflict, MAC Address Conflict, FTP Server Exception |
Video Analytics |
Crowed, Video Abnormal, Audio Abnormal, Heat Map |
Tripwire, Double Tripwire, Perimeter, Object Abandon, Object Lost, Loitering, Running, Parking, |
Feature |
Image |
Camera |
Lens |
Illuminator |
Compression Standard |
