| Image Sensor 1/2.8″ CMOS |
| Signal System PAL/NTSC |
| Min. Illumination Color: 0.01Lux@ (F1.6, ACG ON), B/W: 0Lux with IR |
| Shutter Time 1s to 1/100,000s |
| Day & Night Dual IR Cut Filter with Auto Switch |
| Wide Dynamic Range 120dB |
| Angle Adjustment Bracket, pan 0~360°, tilt 0~75°, roate 0~360° |
| Lens |
| Lens Type Motorized |
| Focus 2.7-13.5mm |
| Lens Mount 14 |
| Aperture F1.6~F3.3, Fixed |
| FOV Horizontal field of view: 102.7°~29° |
| Illuminator |
| IR LEDs 4 |
| IR Range Up to 80m |
| Wavelength 850nm |
| White/Warmlight LEDs N/A |
| Compression Standard |
| Video Compression S+265/H.265/H.264/M-JPEG |
| Video Bit Rate 32Kbps~16Mbps |
| Audio Compression G.711A/G.711U/ADPCM/AAC |
| Audio Bit Rate 8K~48Kbps |
| Image |
| Max. Resolution 3840×2160 |
Third Stream
PAL: 25fps(1280×720, 704×576, 704×288, 640×360, 352×288)
NTSC: 30fps(1280×720, 704×480, 704×240, 640×360, 352×240) |
| Image Setting Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
| Image Enhancement BLC/3D DNR/HLC/Corridor Format |
| ROI Support 8 fixed regions of coding |
OSD 16 16, 24 24, 32 32, 48 48, 64×64, 96×96, adaptable size, Letters Such as Week, Date, Time, Total 8
Regions |
| Picture Overlay Yes |
| Privacy Mask Yes, 8 regions |
| Smart Defog Yes |
| Feature |
Alarm Trigger Event Input, Event Output, Motion Detection, Mask Alarm, Disk Full, Disk R/W Error, IP Address
Conflict, MAC Address Conflict, FTP Server Exception |
Video Analytics
Tripwire, Double Tripwire, Perimeter, Object Abandon, Object Lost, Loitering, Running, Parking,
Crowed, People Counting, On Duty Detection, Video Abnormal, Audio Abnormal, Heatmap,
Face Capture(Face Detection), Safety Helmet Detection, Human/Vehicle Classification |
| Early Warning(EW) N/A |
| PAL: 20fps (3840×2160, 3072×2048), 25fps (2560×1440, 2304×1296, 1920×1080, 1280×720) |
| NTSC: 20fps (3840×2160, 3072×2048), 30fps (2560×1440, 2304×1296, 1920×1080, 1280×720) |
| PAL: 25fps (704×576, 704×288, 640×480, 352×288) |
| NTSC: 30fps (704×480, 704×240, 640×480, 352×240) |
دانلود دیتاشیت دوربین تیاندی مدل TC-C38TS
