dB |
Angle Adjustment Bracket, pan 0~360°, tilt 0~75°, roate 0~360° |
Lens |
Lens Type Fixed |
Focus 2.8mm/4mm |
Lens Mount M12 |
Aperture F1.6, Fixed |
FOV Horizontal field of view: 95.6° (2.8mm)/77.9° (4mm) |
Illuminator |
IR LEDs 2 |
IR Range Up to 50m |
Wavelength 850nm |
White/Warmlight LEDs N/A |
Compression Standard |
Video Compression S+265/H.265/H.264/M-JPEG |
Video Bit Rate 32Kbps~16Mbps |
Audio Compression G.711A/G.711U/ADPCM/AAC |
Audio Bit Rate 8K~48Kbps |
Image |
Max. Resolution 2592×1944 |
Main Stream
PAL: 25fps (2592×1944, 2592×1520, 2560×1440, 2304×1296), 50fps (1920×1080, 1280×720)
NTSC: 30fps (2592×1944, 2592×1520, 2560×1440, 2304×1296), 60fps (1920×1080, 1280×720) |
Sub Stream
PAL: 25fps (704×576, 704×288, 640×360, 352×288)
NTSC: 30fps (704×480, 704×240, 640×360, 352×240) |
Third Stream
PAL: 25fps(1920×1080, 1280×720, 704×576, 704×288, 640×360, 352×288)
NTSC: 30fps(1920×1080, 1280×720, 704×480, 704×240, 640×360, 352×240) |
Image Setting Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
Image Enhancement BLC/3D DNR/HLC/Corridor Format |
ROI Support 8 fixed regions of coding |
OSD
16×16, 32×32, 48×48, 64×64, adaptable size, Letters Such as Week, Date, Time, Total 8 Regions |
Picture Overlay Yes |
Privacy Mask Yes, 4 regions |
Smart Defog Yes |
Feature |
Alarm Trigger Event Input, Event Output, Motion Detection, Mask Alarm, Disk Full, Disk R/W Error, IP Address
Conflict, MAC Address Conflict, FTP Server Exception, Voltage Abnormal |
Video Analytics
Tripwire, Double Tripwire, Perimeter, Object Abandon, Object Lost, Loitering, Running, Parking,
Crowed, People Counting, On Duty Detection, Video Abnormal, Audio Abnormal, Heatmap,
Face Capture(Face Detection), Safety Helmet Detection, Human/Vehicle Classification |
Early Warning(EW) |
N/A |
