Video Input 80-ch |
Max Resolution 12MP |
Two-way Audio Input 1-ch, 3.5mm |
Bandwidth Income 320Mbps; Outgoing 320Mbps |
Output |
HDMI/VGA Output |
Screen Split 1/3/4/6/8/9/10/13/16/20A/20B/25/32/36/40/64 |
Audio Output 1×3.5mm, 1×BNC |
Decoding |
Decoding Format S+265/H.265/H.264 |
Recording Resolution 12MP/8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Preview Capability |
Synchronous Playback |
Records Encryption Yes |
Hard Disk |
SATA 8 SATA interfaces for 8 HDDs |
Capacity Up to 10TB for each HDD |
eSATA Interface 1 eSATA interface |
Array Type JBOD, RAID0/1/5/6/10 |
External Interface |
Network Interface 2 RJ45 self-adaptive 10/100/1000 Mbps network interfaces |
USB Interface 2 USB 2.0, 1 USB 3.0 |
Serial Interface 2 RS-485, 1 RS-232 |
Alarm In/Out 16/4 |
Network |
Protocol |
System Compatibility ONVIF (PROFILE S/T), SDK, P2P |
General |
Web Version WEB6 |
Language
Simple Chinese, Traditional Chinese, English, Spanish, Korean, Italian, Turkish, Russian, Thai, French,
Polish, Dutch, Hebraism, Arabic (only for UI), Vietnamese(only for UI) |
Operating Conditions -10 ~ 55 , 10%~90% RH |
Power Supply AC100~240V, 50/60HZ |
Redundant Power N/A |
Consumption (without HDD) 100W (without HDD) |
Chassis 2U |
Dimensions |
Weight (without HDD) 7.2Kg (15.87lb) |
