Video Input |
20-ch |
Max Resolution |
8MP |
Two-way Audio Input |
1-ch, 3.5mm |
Bandwidth |
Income 80Mbps; Outcome 80Mbps |
HDMI: 1-ch, 3840×2160, 2560×1600, 2560×1440, 1920×1080, 1280×720, 800 ×600, 1024×768, 1366
×768, 1440×900, 1280×800 |
VGA:1-ch, 1920×1080, 1280×720, 800×600,1024×768, 1366×768, 1440×900, 1280×800 |
Screen Split |
1/3/4/6/8/9/10/13/16/20A/20B |
Audio Output |
1×RCA |
Decoding Format |
S+265/H.265/H.264 |
Recording Resolution |
8MP/6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Preview Capability |
1×4K, 1×5MP, 2×4MP, 4×1080P, 8×720P, 20×4CIF |
Synchronous Playback |
1×4K, 1×5MP, 2×4MP, 4×1080P, 8×720P |
Records Encryption |
Yes |
SATA |
2 SATA interfaces for 2 HDDs |
Capacity |
Up to 10TB for each HDD |
eSATA Interface |
N/A |
Array Type |
N/A |
Network Interface |
1xRJ45 self-adaptive 10/100 Mbps network interface |
USB Interface |
2×USB 2.0 |
Serial Interface |
N/A |
Alarm In/Out |
0/1 |
POE Interface |
16×RJ45 self-adaptive 10/100 Mbps network interface |
Power per POE Port |
30W |
Max Current per POE Port |
600mA |
Web Version |
Web6 |
Language |
English, Russian, Spanish, Korean, Italian, Turkish, Simple Chinese, Traditional Chinese, Thai,
French, Polish, Dutch, Hebraism (UI), Farsi (UI) |
Operating Conditions |
-10℃~ 55℃, 10%~90% RH |
Power Supply |
100~240V AC, 50~60 Hz |
Consumption (without HDD) |
≤25W (without HDD) |
Chassis |
1U |
Dimensions |
45.1×255×231 mm (1.78×10.04×9.09 inch) |
Weight (without HDD) |
3Kg (6.61lb) |
